Food Grade Sanitary Stainless Steel Milk Absorb CIP Self Priming Water Pump stainless steel beer pump
Food grade liquid transfer sanitary centrifugal pump,it is using SUS304,SUS316 or SUS316L stainless steel plate stamping manufacture. Motor is ordinary cast iron motor or explosion proof motor. Can additional SUS304 stainless steel shield. Inlet and outlet is divided into fast spin collar type,internal and external threaded type,flange type and intubation joint type,choose for the buyer. This pump whole design accords with GMP specification requirement,internal and external surface smooth as a mirror,no dead angle,high efficiency energy saving,is accords with green environmental protection product. Widely used for pharmacy,beverage,food,oil,dairy,daily expenses,brewing,environmental protection,water treatment and other trade.
With simple structure, easy dismount, adjustable foot height, vibrationproof device, low noise,high efficiency, long-term normal operation, easy maintenance,gentle and tender treatment , of materials this sanitary centrifugal pump series is your ideal choice. It complies with food sanitary standard and guarantees original taste of your products.
1 . Pump body; 2 . Shaft cap; 3 . Impeller; 4 . Mechanical seal dynamic ring ; 5 . Pump body Oring 6 . Mechanical seal static ring;
7 . Impeller seat;8 . Static ring seat;9 . Spring;10 . Retainer ring11 . Snap spring;12 . Nameplate;13 . Support; 14 Pump shaft ;15 . Straining ring;
16 . Straining sleeve ;17 . Motor;18 Pump foot;19 . Housing
open type impeller, there is no dead end
Max O 1MPa water Lt:0.25-0.5L/min
Max Inlet Pressure
-10ºC to +140ºC(EPDM)
Health centrifugal pump is a few horizontal transport of high and low level, is not the self- priming
the part contact with medium is polished and other partisglass painted and sand blasted
Packaging and transp
|Q1||Are you trade or manufacturer?|
We are a factory with an international sales company specialized in support for global distributors.
|Q2||Can you provide instant technical consulting services?|
|A||We are able to discuss technical details and offer suggestions over the phone in English.|
You can get the answers in minutes, instead of days.
What's the difference between Ready-To-Ship and Customized products?
Some of RTS standard products are in stock and ready to ship in 2-3 days.
We can also quick design and make the drawings for customer requirements, then begin the production.
|Q4||What is the payment terms?|
We accept Alibaba Trade Assurance Order, also can T/T and L/C.
|Q5||How to choose the shipment way?|
It is according to the order quantity, delivery time, costs and customs policy etc. (Or decide by customers)
How about the after-sales service?
|A||Fast after-sales support. Our products have a one-year warranty and free permanent consulting services.|
